Rapid Fittings For Plastic Tube/ Push On Fittings / Brass Quick Fittings - NPT, BSPT thread |
|
Product Description |
1.Rapid Fittings fittings can be used with rigid nylon tubes. |
2.Nickel-plated brass bodies ensures anti-corrosion and anti-contamination |
3.Thread: BSPT,NPT,Metric threads |
4.A locking nut is provided and can be tightened both manually and with a spanner.
|
5.The special shape of the guiding cone ensures that the tube can not be accidentally cut. |
|
|
Features |
1. Ideally use in vacuum systems & confined spaces where tight bend radii are required |
2. Recommend Plastic Tube: PA polyethylene braided PVC rilsan polyurethane, also be used with rigid PA tubes. |
3. For simple and quick connection of pneumatic circuits even without the use of a spanner. |
4. Unique barb shape ensures good grip on tube even if just tightened by hand. |
5. The special shape of the guiding cone avoid that the tube rupture accidentally. |
6. Corrosion resistant thanks to Nickel plated. |
7. Tubing locking nuts included. |
|
|
Installation Instructions |
1. Ensure that the end of the tube is cut square and is free from burrs. |
2. Place the knurled nut over the tube, See figure 1 |
3. Push the tube over the barbed end of the fitting up to the tube stop. See figure 2 |
4. Screw the knurled nut onto the fitting until finger or wrench tight. (The hexagon on the nut is to aid release), See figure 3 |
Interchange: Camozzi - Rapid Fittings, Norgren - Push-On Tube Fittings, Pneumax - Quick Fittings…. |
|
Specification |
1. Material: Nickel-Plated Brass |
2. Media: Compressed air low pressure fluids |
3. Thread: BSPP & BSPP as standard, other styles available on request. |
4. Operating pressure: Vacuum -15 bar (mainly depending on tube's endurance) |
5. Temperature: -18°C to +70°C. |
|
|
|
Rapid Screw Fittings For Plastic Tube ( Material: Nickel-Plated Brass ) |
|
MODEL: RPM |
Union Bulkhead Rapid Screw Fittings For Plastic Tube |
|
|
|
Metric Size |
MODEL |
OD. Size |
ID. Size |
Description |
RPM 4-2.5 |
4mm |
2.5mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 4mm*2.5mm |
RPM 6-4 |
6mm |
4mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 6mm*4mm |
RPM 8-5 |
8mm |
5mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 8mm*5mm |
RPM 8-6 |
8mm |
6mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 8mm*6.0mm |
RPM 10-6.5 |
10mm |
6.5mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 10mm*6.5mm |
RPM 10-8 |
10mm |
8mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 10mm*8mm |
RPM 12-8 |
12mm |
8mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 12mm*8mm |
RPM 12-10 |
12mm |
10mm |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 12mm*10mm |
Inch Size |
MODEL |
OD. Size |
Description |
RPM 1/4 |
1/4 |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 1/4 |
RPM 5/16 |
5/16 |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 5/16 |
RPM 3/8 |
3/8 |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 3/8 |
RPM 1/2 |
1/2 |
Union Bulkhead Rapid Screw Fittings For Plastic Tube 1/2 |
|
|
|
|
|
|
|
|
|
|
|
