products Home - NTA DOT Air Brake Compression Fittings - Male Adapter
Pneumatic Connection Solutions: Pneumatic FittingsAir Fittings, Push To Connect Fittings,  Pneumatic Connectors.

NTA Series DOT AIR BRAKE COMPRESSION FITTINGS FOR J844 TUBING, DOT Air Brake Fittings

Product Description

NTA DOT Air Brake Compression Fittings For Nylon Tubing

Conformance - Meets specifications and standards of SAE J246, SAE J1131 and DOT FMVSS 571.106.

Applications

Air brake systems or in cab air controls, Use with SAE J844 Type A and B nylon tubing, except where temperatures exceed +200°F(+93°C) or where battery acid can drip on tubing.

Features

  1. Construction - Three piece unit: body, nut and sleeve. Extruded(CA360) and Forged(CA377) Configuration.
  2. Vibration resistance - Fair resistance.
  3. Advantages - Easy to assemble (no tube preparation or flaring required.) Built in tube support and ribbed sleeve for compression and positive grip. May be used with copper tubing by using long nut and spherical sleeve (DOT Air Brake Fittings For Copper Tubing). Insert should be removed for copper tubing use.

Specification

  1. Temperature Range: Fittings will withstand variations from -40°F to +200°F (-40°C to +93°C)
  2. Working Pressure: Maximum operating pressure of 150 psi.

Assembly Instructions

DOT Air Brake Fitting(Nylon Tubing) DOT AIR BRAKE FITTINGS, DOT FITTINGS, DOT COMPRESSION FITTINGS
  1. Cut tubing to desired lengths quarely, maximum of 15° angle allowable. Check that port or mating part is clean and free of debris.
  2. Slide nut and then sleeve on tubing. Threaded end of nut "A" must face toward connector body.
  3. Insert tubing into the preassembled fitting. Make sure tubing is bottomed in connector.
  4. Tighten nut with wrench until one thread remains visible on the fitting body, this will allow for a number of remakes; or, the nut should be screwed down finger tight, then the wrench-tightened as indicated in the following table.
Thread available : NPT, UNF, BSPT (R) , BSPP (G), Metric Thread
NPT & UNF Thread: 10-32 UNF, 1/16, 1/8, 1/4, 3/8, 1/2, 3/4
BSPT (R) Thread: 1/8, 1/4, 3/8, 1/2, 3/4
BSPP (G) Thread: 1/8, 1/4, 3/8, 1/2, 3/4
Metric Thread: M10x1.0, M12x1.5, M14x1.5, M16x1.5, M22x1.5
Tube (OD) available Inch Tube (SAE J844), Metric Tube (DIN 74324)
Inch Tube Size (SAE J844): 1/8, 3/16, 5/32, 1/4, 5/16, 3/8, 1/2, 5/8, 3/4
Metric Tube Size (DIN 74324): 4mm, 6mm, 8mm, 10mm, 12mm, 15mm, 16mm
DOT fittings certificate DOT Certificate (NHTSA)
  NTA Series DOT AIR BRAKE COMPRESSION FITTINGS FOR SAE J844 TUBING
Male Adapter

Male Adapter NTA DOT air brake compression Union bulkhead fittings, DOT Air brake fittings, Pneumatic Fittings

DOT AIR BRAKE COMPRESSION FITTINGS - Male Adapter

Inch Size Tube - NPT Thread

MODEL Tube (OD) Size Thread Size Description
DQPC 1/8-1/16NPT 1/8 1/16NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/8 1/16NPT
DQPC 1/8-1/8NPT 1/8 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/8 1/16NPT
DQPC 3/16-1/16NPT 3/16 1/16NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/16 1/16NPT
DQPC 3/16-1/8NPT 3/16 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/16 1/8NPT
DQPC 3/16-1/4NPT 3/16 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/16 1/4NPT
DQPC 1/4-1/16NPT 1/4 1/16NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/4 1/16NPT
DQPC 1/4-1/8NPT 1/4 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/4 1/8NPT
DQPC 1/4-1/4NPT 1/4 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/4 1/4NPT
DQPC 1/4-3/8NPT 1/4 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/4 3/8NPT
DQPC 1/4-1/2NPT 1/4 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/4 1/2NPT
DQPC 5/32-1/16NPT 5/32 1/16NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/32 1/16NPT
DQPC 5/32-1/8NPT 5/32 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/32 1/8NPT
DQPC 5/32-1/4NPT 5/32 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/32 1/4NPT
DQPC 5/32-3/8NPT 5/32 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/32 3/8NPT
DQPC 3/8-1/8NPT 3/8 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/8 1/8NPT
DQPC 3/8-1/4NPT 3/8 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/8 1/4NPT
DQPC 3/8-3/8NPT 3/8 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/8 3/8NPT
DQPC 3/8-1/2NPT 3/8 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/8 1/2NPT
DQPC 1/2-1/4NPT 1/2 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/2 1/4NPT
DQPC 1/2-3/8NPT 1/2 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/2 3/8NPT
DQPC 1/2-1/2NPT 1/2 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/2 1/2NPT
DQPC 1/2-3/4NPT 1/2 3/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 1/2 3/4NPT
DQPC 5/8-3/8NPT 5/8 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/8 3/8NPT
DQPC 5/8-1/2NPT 5/8 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/8 1/2NPT
DQPC 5/8-3/4NPT 5/8 3/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 5/8 3/4NPT
DQPC 3/4-1/2NPT 3/4 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/4 1/2NPT
DQPC 3/4-3/4NPT 3/4 3/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 3/4 3/4NPT

Metric Size Tube - NPT Thread

MODEL Tube (OD) Size Thread Size Description
DQPC 4-1/8NPT 4mm 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 4mm 1/8NPT
DQPC 6-1/8NPT 6mm 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 6mm 1/8NPT
DQPC 6-1/4NPT 6mm 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 6mm 1/4NPT
DQPC 8-1/8NPT 8mm 1/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 8mm 1/8NPT
DQPC 8-1/4NPT 8mm 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 8mm 1/4NPT
DQPC 8-M12 8mm M12*1.5 NTA DOT Air Brake Compression Fittings Male Adapter 8mm M12*1.5
DQPC 8-3/8NPT 8mm 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 8mm 3/8NPT
DQPC 10-1/4NPT 10mm 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 10mm 1/4NPT
DQPC 10-3/8NPT 10mm 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 10mm 3/8NPT
DQPC 10-1/2NPT 10mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 10mm 1/2NPT
DQPC 12-1/4NPT 12mm 1/4NPT NTA DOT Air Brake Compression Fittings Male Adapter 12mm 1/4NPT
DQPC 12-3/8NPT 12mm 3/8NPT NTA DOT Air Brake Compression Fittings Male Adapter 12mm 3/8NPT
DQPC 12-1/2NPT 12mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 12mm 1/2NPT
DQPC 14-1/2NPT 14mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 14mm 1/2NPT
DQPC 15-1/2NPT 15mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 15mm 12NPT
DQPC 16-1/2NPT 16mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 16mm 1/2NPT
DQPC 18-1/2NPT 18mm 1/2NPT NTA DOT Air Brake Compression Fittings Male Adapter 18mm 1/2NPT




PACE air brake DOT compression fittings meet SAE J246, SAE J1131 and D.O.T. FMVSS571.106 specifications.

PACE fittings have a pre-applied thread sealant on all male pipe threads. Electroless nickel plated bodies can be used with bio-diesel. Use with the following

SAE J844 tubing• 1120 Nylon Air Brake Tubing • 1320 Quantum Elastomeric Air Brake Tubing Markets: • Heavy duty truck • Trailer • Mobile Features/Benefits: • D.O.T. compression style fittings for repairing truck and trailer air brake lines • For use in air brake systems on semi-trucks, trailers, buses, mobile equipment and farm implements • Ribbed sleeve for compression and positive grip • Stainless Steel tube support • Meets D.O.T. FMVSS 571.106, SAE J246 and SAE J1131 • Electroless nickel plated bodies can be used with bio-diesel • All brass air brake fitting • Use with J844 type A & B nylon tubing in air brake systems • Pre-applied thread sealant Applications: • Air brakes • Air tanks • Air ride • Sliders • Tire inflation • Primary & secondary air lines • Cab controls Custom configurations and sizes are available upon request.



One touch tube fitting, Push in fitting, Air fitting, pneumatic fitting, Push To Connect Tube fittings, All metal push in fitting, brass air fittings, Steckverschraubungen, Pneumatik-Zubehör, Pneumatyka, Drosselrückschlagventile, alle Gewindefittinge mit geradem G-Gewinde, NPT-Gewinde, NEUMÁTICA RACORES, Pneumatique raccord, Raccorderia.Plastic Pneumatic Fitting, Pneumatic Accessories, Pneumatic Push in Fittings, One Touch Fittings, Nickel Plated Brass Push in Fittings, Air Flow Control valve, Pneumatic flow control valve, Hand Valve, Air Silencer, Air Muffler, Nylon Tubing, Air Tubing, Quick Coupler, Air Line Fittings, Airline Fittings, Quick coupling, Push to Connect Fittings, Air Tubing, Pneumatic Fittings, Push in Fittings, air fittings, Instant fittings, Push To Connect Fittings, One Touch Fittings, One Touch Tube Fittings, Metal Push in Fittings, Brass Air Fittings, Metal Instant Fittings, Brass Instant Fittings, Metal One Touch Fittings, Brass One Touch Fittings, Compact One Touch Fittings, Air Fittings, air Silencers, Air Muffler, Air Fittings, Push To Connect Tube Fittings, Pneumatic Silencer, Pneumatic Muffler, Push in Instant Fittings, Tube Fittings, Air Quick Fit Fittings, Speed Controllers, Hand Valves, Air Blow Guns, Nickel Plated Push in Fittings, Metal Fittings, Mini Fittings, Quick Coupler, Quick Push to Connectors, Brass Fittings, Miniature Pneumatic, Pneumatic fitting, Metric Push in Fittings, PU Tubing, Compact One Touch Fittings with O-ring, Flow Controller, Exhaust Silencer, Pneumatic Couplings, Push fitting for PU Tube, all brass air Fittings, Swivel Fittings, Air Dust Guns, Hand Throttle Valves, Pneumatik Fittings, Mini Silencers, Inch Push in Fittings, Inch Instant Fittings, Metric Instant Fittings, air one touch Fittings, pneumatic push on Fittings, Push in Fittings, Push to Connect Fittings, Push Fit Fittings, Quick Release Coupling, Pneumatic Fittings, Check valve, Stop Valve, Compression Fittings, air connectors, Pneumatic Connectors, DOT Fittings, Air Brake Fittings, DOT air brake fittings, Air Flow Control Valve, pneumatic component

Pneumatic Fittings, with NPT or BSPT Quick Coupler Air Silencer Air Blow Gun Air Hose
Pneumatic Connectors Push In Fittings With O-ring Push To Connect Fittings Air Fittings Pneumatic Component


facebook twitter linkedin google+ flicker RSS feed
COMPANY INFO PRODUCTS CUSTOMER SERVICE LOCATION
About Us Composite Push In Fittings FAQ's
No.11, AnXing Road, ZhangQi Town,
CiXi, NingBo City, China. 315313
pace@china-pace.com
Tel: (86) 1538 194 5096
Contact Us DOT Push To Connect Air Brake Fittings Returns & Exchange
News Stainless Steel Push In FIttings Request Quote
Privacy Policy Nickel Plated Brass Push In Air Fittings Site Map
Copyright © 2018 NingBo Pace Pneumatics Co., Ltd. - Chinese Manufacturer
