| Application |
Features |
| A additional seal provides a double tight on the tube, thus ensuring a highly reliable connection and avoiding any possible leakage that may occur. Connection and disconnection of the tube can be repeated several times without the use of proper tools and without compromising the performance of the fitting ot the sealing on the tube. The NBR seals are standard and can be easily replaced with FKM and EDM seals |
Pressure generally be limited by the type of tubing used. |
| Push to connect: Polyamide (PA) 6 - 11 - 12, PU, Hytrel Polyester |
| All fluids compatible with the fitting's materials requiring a leak-tight seal, e.g. water. For other fluids, please contact our technicians. |
| Construction |
|
 |
|
| Specification |
|
| Fluid |
Air, Vaccum, Oil, liquid, Water |
|
| Pressure Range |
0~6.0 MPa |
|
| Material |
Nickel-plated brass |
|
| Max Pressure |
10.0 Mpa |
|
| Temperature Range |
-20°C - 80°C (NBR Sealing) |
|
| Applicable Tube |
PU (Polyurethane) |
PA (Nylon) |
|
| |
|
| Dual Sealing Brass Push In Fittings - Lubrication Systems Fittings |
 Catalogue |
|
|
|
 |
Lubrication Systems Fittings
High Pressure Check Valve
|
Lubrication Systems Fittings
Double Sealing Male Straight
|
Lubrication Systems Fittings
Double Sealing Male Straight
|
Lubrication Systems Fittings
Double Sealing Male Elbow
|
|
|
|
|
 |
Lubrication Systems Fittings
Double Sealing Union Y
|
Lubrication Systems Fittings
Double Sealing Union Tee
|
Lubrication Systems Fittings
Double Sealing Female Straight
|
Lubrication Systems Fittings
Double Sealing Schrader Valve
|
|
|
| Accpet: Custom Made Lubrication Systems Fittings for Metric Tube, UNF Thread, BSPP Thread, Metric Thread, Any other Sizes and Types |
|
|
|
|
|
|
